EdgeNode Titan

EdgeNode Titan: Advanced Industrial IoT Gateway for Medium to Large Facilities

Name: N2 IoT Gateway
Brand: IndustrialIoT Solutions
Price: 45000 INR
Availability: InStock
Rating: 4.8 (156 reviews)

Robust IoT gateway designed for medium to large industrial facilities requiring advanced protocol support, enhanced security, and superior processing power.

Built for demanding industrial environments, the EdgeNode Titan delivers enterprise-grade reliability with dual connectivity options, advanced edge computing capabilities, and comprehensive cybersecurity features.

Available Models

Choose the configuration that matches your requirements

Titan Standard

Advanced connectivity for medium facilities

4G LTE / 3G / 2G Support
2.4 GHz Wi-Fi & GNSS
2x Digital Inputs (0-24V)
4x Analog Inputs (4-20mA)
RS485 & Ethernet Interface

Titan Pro

Premium features for demanding applications

800 mAh Backup Battery
TLS 1.2 Security & MQTT
Rule Engine & Edge Scripting
SD Card Data Logging
Industrial Protection (EFT/ESD)

Advanced Features

Enterprise-grade capabilities for demanding industrial applications

Multi-Connectivity

Global 4G-LTE FDD/TDD support with 2.4 GHz Wi-Fi and Ethernet for seamless industrial networking.

Embedded Security

Secure data transmission using TLS 1.2 and protocol support for MQTT, HTTP, HTTPS, and TCP/IP.

Edge Intelligence

Built-in Rule Engine and Scripting capabilities for local logic processing and edge analytics.

Power Resiliency

Wide 12–30V DC input with reverse polarity protection and an 800 mAh Li-ion backup battery.

FOTA & GNSS

Supports secure Over-the-Air firmware updates and high-precision GPS/GLONASS positioning.

Industrial I/O & Logging

Equipped with 4x Analog (4-20mA), 2x Digital inputs, RS485, and SD card-based data logging.

Why Choose EdgeNode Titan?

Advanced capabilities that deliver superior performance and reliability

Industrial Reliability - Weather Proof ABS enclosure for harsh environments

Global Connectivity - 4G LTE Multi-band with GNSS (GPS/GLONASS) support

Power Redundancy - Integrated 800 mAh Li-ion backup battery

Advanced Security - TLS 1.2 encryption with MQTT/HTTPS support

High Precision I/O - 4-channel 4-20mA Analog and 24V Digital inputs

Rugged Testing - Certified for EFT, Surge, PFMF, and ESD protection

Questions? Projects? Let’s Collaborate

Want a demo or quick consult? Message us.

Technical Specifications

Comprehensive technical details for the EdgeNode Titan

Power Supply

Supply Voltage:12–30 V DC

Reverse Polarity Protection:0 to -30 V DC

Max Operating Current:< 200 mA

Peak Operating Current:2A (during network activities)

Backup Battery:800 mAh Li-Ion, 3.7 V

Average Power Consumption:< 5 W

Communication

Cellular:4G-LTE FDD B1/B3/B5/B7/B8/B20; LTE-TDD B38/B40/B41; WCDMA B1/B5/B8; 2G-GSM; 3G-GSM

Wi-Fi:2.4 GHz (802.11 b/g/n)

GNSS:GPS, GLONASS

Ethernet:Available

Interfaces (Inputs and outputs)

Digital Inputs:0 - 24V (2 Nos)

Analog Inputs:4-20mA (4 Nos)

Ethernet / Modbus TCP:1 Port

Relay Output:1 Port

Interface:RS485

Internet Security

Security:TLS 1.2

MQTT / HTTP / HTTPS / TCP IP:Yes

Edge Logic:Rule Engine / Scripting

RTC:Yes

Data Logging:Yes (SD Card)

Physical Specification

Dimensions (L×W×H):170 × 110 × 42 mm

Enclosure Material:ABS

Enclosure Protection:Weather Proof

Operating Environment

Operating Temperature:-40 to +85 deg C

Operating Humidity:85 Rh

Vibration:2g, 10-150 Hertz

Level of Protections

EFT / Surge Test:Yes

ESD Test (Body & Air):Yes

PFMF:Yes

Ready to Upgrade to EdgeNode Titan?

Experience the power of advanced industrial IoT connectivity with enhanced security, dual protocols, and superior processing capabilities. Get expert consultation for your project.
